VT4030CL-277

Electronic Neon Power Supply

For direct mount inside channel letters and similar applications

Features

  • UL 2161 listed
  • Complies with CSA22.2, No 107.1 and No. 3
  • Offers open and short circuit protection
  • All models are self-adjusting
  • Automatic overload shutdown feature
  • High power factor
  • Grounding foot and green wire
  • ½” conduit fitting for primary wiring
  • Integral sleeve GTO (length listed below)
  • Utilizes standard fill pressures

Exclusive: These units are protected by Ventex’s patented protective circuitry to prevent false tripping due to capacitive current. Patent #5892646

2-Year Warranty

Category:

SPECS

Input Voltage 277 VAC (±10%) 50/60Hz
Input Current 0.2A rms max.
Power Factor 0.92
Output Frequency Variable
Output Voltage 0V-4,000V
Output Current 30mA
Operating Temperature -30°F to 122°F (-34°C to 50°C)
Driving Distance* (Based on Standard 12mm tube. Deduct one foot from driving footages for each pair of electrodes.)
Neon 1-10 ft (0.3-3.0 m)
Mercury 1-12 ft (0.3-3.7 m)

*See Ventex Luminous Tube Footage Chart for more information.

Exclusive: These units are protected by Ventex’s patented protective circuitry to prevent false tripping due to capacitive current. Patent #5892646

RESOURCES

DIMENSIONS

Length (A) 5.0 in 12.7 cm
Width (B) 1.80 in 4.57 cm
Height (C) 1.40 in 3.60 cm
Mounting (D) 4.50 in 11.4 cm
Mounting (E) 1.18 in 3.0 cm
Weight 15.0 oz 425 g
Primary Leads 36.0 in 91.4 cm
GTO Leads 24.0 in 61.0 cm
