For installation in channel letters, raceway and remote applications


  • Exclusive design saves up to 30% on neon-to-LED retrofits
  • Series wired just like neon with bypass that prevents full string outage
  • Constant current driver eliminates all resistors found on all other LED modules
  • Consistently bright modules no matter the distance from the driver
  • Highly efficient, cool-running design extends LED life
  • Remote mounts up to 300 feet with 18AWG wire
  • Safe, low-current design with GFI, open and short circuit, overload and polarity protection
  • Long driving distances require fewer LED drivers
  • Single-wire design reduces installation time
  • UL Sign Components Manual (SAM) listed
  • UL Classified for rapid retrofit neon-to-LED conversion

5-Year Warranty



Input Voltage (50/60Hz) 277VAC (+/-10%)
Input Current @ Max. Load 0.25A rms
Power Factor 0.90
Output Voltage 0-400VDC (+/-200VDC max. to Gnd)
Output Current (Line Load Regulated) 120mA (Factory Set)
Output Power 50W
Operating Temperature* -30ºF to 122ºF / -34ºC to 50ºC
Input Surge Protection  Varistor Type
Built-in Protection  GFI, Open and Short Circuit, Overload, Reverse Polarity

*When operating at ambient temperature higher than above limit, reduce load by 10% for each 9ºF (5ºC) ambient rise.



Length (A) 4.85 in 12.3 cm
Width (B) 2.0 in 5.0 cm
Height (C) 1.58 in 4.0 cm
Mounting (D) 4.50 in 11.4 cm
Mounting (E) 1.38 in 3.5 cm
Weight 15.0 oz 425 g
Primary Leads 18.0 in 45.7 cm
Output Leads 18.0 in 45.7 cm
