VLP200-120

For installation in channel letters, raceway and remote applications

Features

  • Conservatively powered at less than 65% of the LED’s maximum rated current extends useful life and reliability
  • Exclusive ability to save up to 30% on neon-to-LED retrofits
  • Remote mounts up to 150 feet with 18AWG wire with no loss of light
  • Safe, low-current design with GFI, open and short circuit, overload and polarity protection
  • Illuminates brighter than 6,500 mercury argon
  • Single-wire design simplifies factory installation
  • Brightest, most energy-efficient LED available
  • UL Sign Components Manual (SAM) listed
  • UL Classified for rapid retrofit neon-to-LED conversion

5-Year Warranty

Category:

SPECS

Input Voltage (50/60Hz) 120VAC (+/-10%)
Input Current @ Max. Load 0.65A rms
Power Factor  0.95
Output Voltage 0-250VDC (+/-200VDC max. to Gnd)
Output Current (Line Load Regulated) 250mA (Factory Set)
Output Power 55W max.
Operating Temperature* -30ºF to 122ºF/ -34ºC to 50ºC
Input Surge Protection  Varistor Type
Built-in Protection  GFI, Open and Short Circuit, Overload, Reverse Polarity

*When operating at ambient temperature higher than above limit, reduce load by 10% for each 9ºF (5ºC) ambient rise.

RESOURCES

DIMENSIONS

Length (A) 4.85 in 12.3 cm
Width (B) 2.0 in 5.0 cm
Height (C) 1.58 in 4.0 cm
Mounting (D) 4.50 in 11.4 cm
Mounting (E) 1.38 in  3.5 cm
Weight 15.0 oz 425 g
Primary Leads 18.0 in 45.7 cm
Output Leads 18.0 oz 45.7 cm
