VLP125SPD-120

For installation in channel letters, raceway and remote applications

Features

  • Drives 25% more output than the 100 Series
  • Soft start eliminates spikes at turn-on or when power is interrupted
  • More robust surge protection across all three input lines (L-N, L-G, N-G)
  • Higher voltage switching FETs for more sustained surge protection
  • Improved output transfer performance
  • Remote mount driver up to 300 feet from LED Load
  • Output wires are both white, with polarity arrows to simplify connection

NOTE: Although LED Drivers and LED modules will not be damaged by reverse polarity, no light will be produced.

Category:

SPECS

Input Voltage (50/60Hz) 120VAC (+/-10%)
Input Current @ Max. Load 0.63A rms
Power Factor 0.90 min
Output Voltage 0-500VDC (+/-250VDC max. to Gnd)
Output Current (Line Load Regulated) 125mA (Factory Set)
Output Power 62.5W
Operating Temperature* -30ºF to 122ºF / -34ºC to 50ºC
Input Surge Protection ANSI C62.41 Class C / Level High
Built-in Protection GFI, Open and Short Circuit, Overload, Reverse Polarity

*When operating at ambient temperature higher than above limit, reduce load by 10% for each 9ºF (5ºC) ambient rise.

RESOURCES

DIMENSIONS

Length (A) 6.75 in 17.1 cm
Width (B) 2.0 in 5.0 cm
Height (C) 1.58 in 4.0 cm
Mounting (D) 6.50 in 11.4 cm
Mounting (E) 1.38 in  3.5 cm
Weight 18.0 oz 510 g
Primary Leads 18.0 in 45.7 cm
Output Leads 18.0 oz 45.7 cm
